Baureihe AgieCharmilles CUT 1000

Entwickelt für herausragende Genauigkeit
Die Baureihe CUT 1000 von GF Machining Solutions wurde speziell für die Anforderungen an Mikrobearbeitung entwickelt und bietet einzigartige Merkmale in Bezug auf Präzision und Produktivität sowie perfekte Vorhersehbarkeit in Sachen Wiederholbarkeit von Bearbeitungsergebnissen.

CUT 1000 – CUT 1000 OilTech

CUT 1000 OilTech

Die Baureihe CUT 1000 in der Version OilTech wurde für hervorragende Oberflächenintegrität und Oberflächengüte entwickelt. Reduzieren Sie die Anzahl der Schnitte, die für eine optimale Oberflächengüte erforderlich sind.

CUT 1000 OilTech

Spezifikationen

CUT 1000

Main Specifications

Main Specifications

Travel X, Y, Z

220 x 160 x 100 mm

8.66 x 6.3 x 3.93

Min. surface roughness RA 0.05 μm
Max. taper angle / height

3/80°  mm

3/3.14° in

Max. workpiece dimensions *

300 x 200 x 80 mm

11.81 x 7.87 x 3.14 in

Max. workpiece weight

35 kg

77 lbs

Workpiece

Workpiece

Travel U, V

± 40 mm

± 1.57 in

Wire diameters

0.07 - 0.20 (0.02-0.05 optional) mm

0.003 - 0.008 (0.0008 - 0.002 optional) in

Max. wire spool weight 2x8 kg

* Width x depth x height

CUT 1000 Oiltech

Main Specifications

Main Specifications

Travel X, Y, Z

220 x 160 x 100 mm

8.66 x 6.3 x 3.93

Min. surface roughness RA 0.05 μm
Max. taper angle / height

3/80°  mm

3/3.14° in

Max. workpiece dimensions *

300 x 200 x 80 mm

11.81 x 7.87 x 3.14 in

Max. workpiece weight

35 kg

77 lbs

Workpiece

Workpiece

Travel U, V

± 40 mm

± 1.57 in

Wire diameters

0.07 - 0.20 (0.02-0.05 optional) mm

0.003 - 0.008 (0.0008 - 0.002 optional) in

Max. wire spool weight 2x8 kg

* Width x depth x height
