Hole drilling

Simply drill holes in multiple configurations
AgieCharmilles DRILL E 300 is a high-speed drill machine widely used for drilling starting holes. In aerospace for aircraft engines, as well as gas turbines in energy production, cooling holes are needed for creating a film of cooling air on the surface of turbine blades and vanes to prevent them from overheating. The DRILL E 300 is the perfect solution when you need to add small holes on a part with inclined faces or hard-to-reach positions.


Shorten your setup time

Process monitoring and optimization are implemented via the operator console. Sensors for short circuits, temperature and liquid level ensure safe operation. Numerical controlled X, Y and Z axes and a variety of touching cycles offer convenience to the operator when setting up.

Make your life easier

Data input on the operator console is quick and simple. Technology settings are selected automatically by material electrode / piece, piece height and electrode diameter. Touching cycles can be programmed and called up with a few commands.

DRILL E 300

Please accept all cookies to view the external content.

AgieCharmilles DRILL E 300
AgieCharmilles DRILL E 300
1/

Maximum drilling depth

With drilling depths of up to 200 mm (7.78 in), DRILL E 300 is the ideal vertical drill for an extensive range of applications.

Fine electrode technology

Its technology for fine electrodes Ø0.1 – 0.3 mm (0.004 – 0.012 in) make the DRILL E 300 suitable for drilling fine start holes on lead frames or high-speed stamping molds.

Simply drill holes in multiple configurations

Simply drill holes in multiple configurations

Whatever the need, whether for small, large, through or blind holes, for single and multi-hole patterns, the adapted technology is automatically selected.

Specifications

DRILL E 300

Main Specifications

Main Specifications
Electrode diameter 0.3 up to 3 mm (option: 0.10, 0.15, 0.20 mm)
0.004 up to 0.12 in (option: 0.004, 0.006, 0.008 in)
Maximum drilling depth 200 mm
7.78 in
Maximum workpiece weight 300 kg
660 lb
Travel paths of axes X, Y and Z 300 x 200 x 300 mm
11.8 x 7.8 x 11.8 in
Worktable size (width x length) 400 x 300 mm
15.7 x 11.8 in
Rotating spindle 57.5 rpm
Travel path of the electrode guide 100 mm
3.9 in
Heavy duty generator 30 A
Dielectric volume 16 l
4.2 us gal
Mains connections 3 x 400 V
50/60 Hz
Maximum power consumption 5 kW
Display TFT Touch screen, 12.1”
Pump operating pressure 70 bar
Machine dimensions 1345 x 940 x 2040 mm
52.9 x 37 x 80.3 in
Total weight of the machine 870 kg
1918 lbs

Options: fine drill holders and guides, filtration system, deionization unit, AC CAM DRILL
