구멍 드릴링

다양한 구성으로 간단하게 구멍 뚫기
AgieCharmilles DRILL 20은 시작 구멍 드릴링에 널리 사용되는 고속 드릴 기계입니다. 항공기 엔진용 항공우주 및 에너지 생산용 가스 터빈의 경우, 터빈 블레이드와 날개 표면에 냉각 공기막을 형성하여 녹지 않도록 하려면 냉각 구멍이 필요합니다. 기계는 5축 구성을 활용해 어떤 각도에서라도 경사진 표면 공작물에 구멍을 뚫을 수 있습니다.

DRILL 20

규격

DRILL 20

Main Specifications

Main Specifications

Electrode diameter

0.1 up to 3 mm

0.004 up to 0.12 in

Maximum drilling depth

200 mm

7.78 in

Maximum workpiece weight

300 kg

660 lb

Travel paths of axes X, Y and Z

300 x 200 x 300 mm

11.8 x 7.8 x 11.8 in

Worktable size *

400 x 300 mm

15.7 x 11.8 in

Travel path of the electrode guide

100 mm

3.9 in

Heavy duty generator 30 A
Dielectric volume

16 l

4.2 us gal

Mains connections

3 x 400 V

50/60 Hz

Maximum power consumption 5 kVA
Display TFT Touch screen, 12.1”
Pump operating pressure 70 bar
Machine dimensions

1340 x 910 x 1940 mm

52.7 x 35.8 x 76.4 in

Total weight of the machine

870 kg

1918 lbs

Options: fine drill holders and guides, filtration system, deionization unit, AC CAM DRILL
