穴あけ加工

複数構成でシンプルな穴あけドリル加工
AgieCharmilles DRILL E 300は、もみつけ穴の加工に広く使用されている高速穴あけ放電加工機です。航空機のエンジンやガスタービンでは、タービンブレードやベーンの過熱を防ぐために、表面に冷却空気の膜を形成するための冷却穴が必要です。DRILL E 300は、傾斜面や届きにくい位置にある部品に小さな穴を追加する場合に最適な加工ソリューションです。


DRILL E 300

仕様

DRILL E 300

Main Specifications

Main Specifications

Electrode diameter 0.3 up to 3 mm (option: 0.10, 0.15, 0.20 mm)
0.004 up to 0.12 in (option: 0.004, 0.006, 0.008 in)
Maximum drilling depth 200 mm
7.78 in
Maximum workpiece weight 300 kg
660 lb
Travel paths of axes X, Y and Z 300 x 200 x 300 mm
11.8 x 7.8 x 11.8 in
Worktable size (width x length) 400 x 300 mm
15.7 x 11.8 in
Rotating spindle 57.5 rpm
Travel path of the electrode guide 100 mm
3.9 in
Heavy duty generator 30 A
Dielectric volume 16 l
4.2 us gal
Mains connections 3 x 400 V
50/60 Hz
Maximum power consumption 5 kW
Display TFT Touch screen, 12.1”
Pump operating pressure 70 bar
Machine dimensions 1345 x 940 x 2040 mm
52.9 x 37 x 80.3 in
Total weight of the machine 870 kg
1918 lbs

Options: fine drill holders and guides, filtration system, deionization unit, AC CAM DRILL
