鑽孔

多種設定實現輕鬆鑽孔
AgieCharmilles DRILL 20 是一種廣泛用於鑽起動孔的高速鑽床。在航空航太領域的航空引擎以及能源生產的燃氣渦輪機中都需要有冷卻孔,以在渦輪機葉片和輪葉的表面上形成一層冷卻空氣以防止其熔化。透過五軸設定,機器可以在傾斜表面的工件上以任意角度鑽孔。

DRILL 20

規格

DRILL 20

Main Specifications

Main Specifications

Electrode diameter

0.1 up to 3 mm

0.004 up to 0.12 in

Maximum drilling depth

200 mm

7.78 in

Maximum workpiece weight

300 kg

660 lb

Travel paths of axes X, Y and Z

300 x 200 x 300 mm

11.8 x 7.8 x 11.8 in

Worktable size *

400 x 300 mm

15.7 x 11.8 in

Travel path of the electrode guide

100 mm

3.9 in

Heavy duty generator 30 A
Dielectric volume

16 l

4.2 us gal

Mains connections

3 x 400 V

50/60 Hz

Maximum power consumption 5 kVA
Display TFT Touch screen, 12.1”
Pump operating pressure 70 bar
Machine dimensions

1340 x 910 x 1940 mm

52.7 x 35.8 x 76.4 in

Total weight of the machine

870 kg

1918 lbs

Options: fine drill holders and guides, filtration system, deionization unit, AC CAM DRILL
