解決您的製造難題

實現高難設計和解決品質不穩的日常難題,且滿足功能性表面的要求,並抓住新商機。我們理解您的急切之需:我們的雷射紋理加工技術可幫助您跟上瞬息萬變的製造業腳步,追求更高的品質要求,同時重視我們所有人面臨的環境挑戰。現在透過更乾淨的技術,掌握最精細的表面紋理加工。

創新無妥協

透過我們開發的解决方案降低技術和經濟掣肘,告別傳統製造限制:在設計新品時,您受到的約束更少,可以更大膽地創新。產品設計存在無限可能。

簡化加工工序

在單個裝置中執行多個操作,以節省時間並簡化工序:在同一台機器上,只需一個裝置,就可以在最複雜的零件上實現雷射紋理加工、雷射噴砂、雷射雕刻和雷射標記操作。

LASER P 600 U - 1000 U - 1200 U - 1200 U 專用

最小光束半徑

選擇最適合您應用的特定透鏡。根據您的需求,有三種類型的透鏡可用於小型三軸雷射細節操作,以及更大規模的五軸作業。我們的五軸雷射紋理加工機器為您打點一切細節,助您取得成功。

雷射來源

為了實現良好的紋理操作,需要使用短脈衝雷射。從 30 到 100 W,我們都有合適的工具來滿足您的期望。我們的雷射 Flexipulse 可以讓您自由地根據您的應用微調品質/速度比:我們的解決方案一切只為您。

雷射技術

毫微秒雷射在品質和速度之間提供了完美的折衷,符合您的需求,是您物有所值的最佳選擇,完美地解決您目前與特定表面紋理加工需求相關的大部分難題。

移動類型

由於我們的五軸雷射燒蝕技術,我們的雷射機器可以將您所需的紋理應用於任何 3D 複雜零件上,從而達到所需的品質。

LASER P 4000 U - 立即來與雷射同行,大展拳腳

GF Machining Solutions 開創性的 AgieCharmilles LASER P 4000 U 讓汽車顏色和裝飾工作坊及產品和内部設計中心得以精進到新的更高層次。借助全數位化工序和可接收 22 噸以上模具的五軸加工解決方案,該機器甚至可以在大型模具(例如大型陽模、門板、儀表板模具)上輕鬆加工最複雜的紋理。

零件重量

汽車市場的趨勢表明,消費者要求以合適的價格獲得更多個性化和更高品質的產品。OEM 廠商需要提高工序效率,以滿足這些要求。AgieCharmilles LASER P 4000 U 幫助您應對這些挑戰,即使加工大型模具,也能達到與小型模具一樣的紋理品質。

X 軸行程

除了重量之外,本機器還提供無與倫比的軸行程,最高可達 4000 x 3000 x 1170 公釐 (X,Y,Z),滿足大量大型應用對高精度雷射加工的要求。

規格

LASER P 600 U

Machine

Machine

Machine dimensions*

2050 x 2280 x 2770 mm

80.7 x 89.8 x 109 in

Approx machine weight

5000 kg

11023 lbs

Focal length

100/160/254 mm

3.9/6.3/10 in

Ytterbium pulsed fibre laser

20 / 30 / 50 / 100 W
Max. power consumption 4 kW

Axes

Axes

X, Y, Z travels

600 x 460 x 830 mm

23.6 x 18.1 x 32.7 in

Laser titling axis A

180, 210 °/s, °

B axis max. speed

180 °/s. °

B axis table diameter

180 mm

7.08 in

Work area

Work area

Max 5 axis machining volume

Ø 370 x 530 ** mm

Ø 14.6 x 20.9 ** in

Max workpiece volume

420 x 530 ** mm

16.5 x 20.9 ** in

Max workpiece weight 5 axis

75 kg

165 lbs

* Width x depth x height ** FL160

LASER P 1000 U

Machine

Machine

Machine dimensions*

2240 x 2605 x 2845 mm

88.2 x 102.6 x 112 in

Approx machine weight

6500 kg

14330 lbs

Focal length

100/160/254 mm

3.9/6.3/10 in

Ytterbium pulsed fibre laser

20 / 30 / 50 / 100 W
Max. power consumption 4 kW

Axes

Axes

X, Y, Z travels

1000 x 550 x 880 mm

39.6 x 21.6 x 34.6 in

Laser titling axis A

180, 210 °/s, °

B axis max. speed

180 °/s. °

B axis table diameter

380 mm

15 in

Work area

Work area

Max 5 axis machining volume

Ø 460 x 4800 ** mm

Ø 18.1 x 18.9 ** in

Max workpiece volume

510 x 480 ** mm

20.1 x 18.9 ** in

Max workpiece weight 5 axis

150 kg

330 lbs

* Width x depth x height ** FL160

LASER P 1200 U

Machine

Machine

Machine dimensions*

2240 x 3395 x 2930 mm

88.2 x 133.7 x 115.3 in

Approx machine weight

8700 kg

19180 lbs

Focal length

100/160/254 mm

3.9/6.3/10 in

Ytterbium pulsed fibre laser

50 / 100 W
Max. power consumption 4 kW

Axes

Axes

X, Y, Z travels

1200 x 900 x 1200 mm

47.2 x 35.4 x 47.2 in

Laser titling axis A

180, 210 °/s, °

B axis max. speed

90 °/s. °

B axis table diameter

800 mm

31.5 in

Work area

Work area

Max 5 axis machining volume

Ø 865 x 790 ** mm

Ø 34.1 x 31.1 ** in

Max workpiece volume

920 x 790 ** mm

36.2 x 31.1 ** in

Max workpiece weight 5 axis

1200 kg

2646 lbs

* Width x depth x height ** FL160

LASER P 1200 U Dedicated

Machine

Machine

Machine dimensions*

2240 x 2605 x 2845 mm

88.2 x 102.6 x 112 in

Approx machine weight

6500 kg

14330 lbs

Focal length

160/254 mm

6.3/10 in

Ytterbium pulsed fibre laser

50 / 100 W
Max. power consumption 4 kW

Axes

Axes

X, Y, Z travels

1200 x 900 x 1200 mm

47.2 x 35.4 x 47.2 in

Laser titling axis A

180, 210 °/s, °

B axis max. speed

180 °/s. °

B axis table diameter

800 mm

31.6 in

Work area

Work area

Max 5 axis machining volume

Ø 510 x 480 ** mm

Ø 20.1 x 18.9 ** in

Max workpiece volume

510 x 480 ** mm

20.1 x 18.9 ** in

Max workpiece weight 5 axis

1200 kg

2646 lbs

* Width x depth x height

LASER P 4000 U

Machine

Machine

Machine dimensions*

7000 x 10000 x 5250 mm

275.6 x 393.7 x 206.7 in

Approx machine weight

32000 kg

70548 lbs

Focal length

330/420 mm

6.3/10/12.3/206.7 in

Ytterbium pulsed fibre laser

50 / 100 W
Max. power consumption 12.5 kW

Axes

Axes

X, Y, Z travels

4000 x 3000 x 1500 mm

157.5 x 118.1 x 59 in

Laser titling axis A

180, 270 °/s, °

B axis max. speed

180, 370 °/s. °

B axis table diameter

 -

 -

Work area

Work area

Max 5 axis machining volume

2800 x 1800 x 1170 mm

110.2 x 70.9 x 46.1 in

Max workpiece volume

4000 x 3000 x 1170 mm

157.5 x 118.1 x 46.1 in

Max workpiece weight 5 axis

20000 kg

44092 lbs

* Width x depth x height ** FL160
