Hole drilling

Simply drill holes in multiple configurations
AgieCharmilles DRILL 20 is a high-speed drill machine widely used for drilling starting holes. In aerospace for aircraft engines, as well as gaz turbines in energy production, cooling holes are needed for creating a film of cooling air on the surface of turbine blades and vanes to prevent them from melting. With its five axis configuration the machine can drill holes at any angles on a inclined surface workpiece.

Shorten your setup time

Process monitoring and optimization are implemented via the operator console. Sensors for short circuits, temperature and liquid level ensure safe operation. Numerical controlled X, Y and Z axes and a variety of touching cycles, offers convenience for the operator when set up.

Make your life easier

The data input on the operator console is quick and simple. Technology settings are selected automatically by material electrode / piece, piece height and electrode diameter. Touching cycles can be programmed and called up with a few commands.

DRILL 20

AgieCharmilles Drill 20
AgieCharmilles Drill 20
1/
Maximum drilling depth

With drilling depths of up to 200 mm (7.78 in), DRILL 20 is the ideal vertical drill for an extensive range of applications.

Fine electrode technology

Its technology for fine electrodes Ø0.1 – 0.3 mm (0.004 – 0.012 in), make this machine suitable for drilling fine start holes on lead frames or high-speed stamping molds.

Simply drill holes in multiple configurations

Simply drill holes in multiple configurations

Whatever the need, for small, large, through or blind holes, for single and multi-hole pattern, adapted technology is automatically selected.

Specifications

DRILL 20

Main Specifications

Main Specifications
Electrode diameter

0.1 up to 3 mm

0.004 up to 0.12 in
Maximum drilling depth

200 mm

7.78 in
Maximum workpiece weight

300 kg

660 lb
Travel paths of axes X, Y and Z

300 x 200 x 300 mm

11.8 x 7.8 x 11.8 in
Worktable size *

400 x 300 mm

15.7 x 11.8 in
Travel path of the electrode guide

100 mm

3.9 in
Heavy duty generator 30 A
Dielectric volume

16 l

4.2 us gal
Mains connections

3 x 400 V

50/60 Hz
Maximum power consumption 5 kVA
Display TFT Touch screen, 12.1”
Pump operating pressure 70 bar
Machine dimensions

1340 x 910 x 1940 mm

52.7 x 35.8 x 76.4 in
Total weight of the machine

870 kg

1918 lbs

Options: fine drill holders and guides, filtration system, deionization unit, AC CAM DRILL
