AgieCharmilles CUT 2000/3000 Series

Link accuracy with productivity

AgieCharmilles CUT 2000/3000 Series is the perfect balance between productivity and accuracy. Extremely accurate, flexible and capable to bring complete and integrated solutions to your manufacturing challenges. Get ready to obtain uncompromised quality of results in accuracy or surface finish to achieve highest part quality and optimize productivity.

Flexibility and efficiency

Simplify your manufacturing process with the ultra-flexible machine and human-machine interface (HMI) concept and reduce delivery time to your customers. Increase reactivity and take on urgent jobs or change your day and night strategies on the fly.

Process automation

Automate your productivity and use large wire for fast, cost-effective roughing, while machining with thin wire to cut fine radii at the best precision. Control the part from design to quality control with a complete integrated solution.

Excellence in results

Deliver the highest precision parts with the CUT X000 series' X-treme precision version. Achieve finest surface finish and avoid oxidation-related issues with the OilTech version. Get the great repeatability thanks to the thermal stabilization independent of workshop conditions, and benefit from our expertise in technology development.

CUT 2000 S/X - CUT 3000 S/X

AgieCharmilles CUT 2000 X
AgieCharmilles CUT 2000 X
AgieCharmilles CUT 2000 S
AgieCharmilles CUT 3000 X
AgieCharmilles CUT 3000 S
AgieCharmilles CUT 3000 S
1/
Two machines in one

The AWC automatically changes wire diameters during machining, allowing complex machining while keeping the process profitable.

Total accuracy and repeatability

Achieve accuracy down to ±1.5 µm for a total positioning accuracy, with this series’ X version, thanks to its special laser calibration method.

Onboard metrology center

Measurement precision: ± 1.0 μm with a 158 x magnification lens. ± 1.5 μm with a 56 x magnification lens.

Automatic Wire Changer (AWC)

Automatic Wire Changer (AWC)

Use large wire for roughing and easily change to small wire to achieve small radii and fine detail definition. Be more productive and save costs by using identical wire diameters: low-cost wire for roughing and high-performance wire for finishing.

Intelligent Spark Protection System (ISPS)

Intelligent Spark Protection System (ISPS)

The ISPS module recognizes difficult machining conditions and automatically adapts the parameters to avoid wire breakage during roughing. The ISPS module benefits from Spark Track technology: It uses the spark distribution data to maximize machining performance and provide complete wire breakage protection.

Integrated Vision Unit (IVU Advance)

Integrated Vision Unit (IVU Advance)

Reduce your measuring equipment investment and save setup time. Take references without a measuring machine and correct machining errors to achieve high quality—all without removing the workpiece.

Easy job. Easy management

Easy job. Easy management

Effortlessly make last-minute modifications to the machining sequence and optimize your productivity by introducing special actions directly inside the job to improve quality and productivity.

AgieCharmilles CUT 2000 OilTech

The CUT X000 series’ OilTech versions are designed to deliver excellent surface integrity and finish. Benefit from the best surface quality for your most demanding applications.

Perfect surface integrity

Confidently machine parts requiring long submersion periods. Forget about typical issues related to cobalt depletion when machining in water.

Reduce the gap

Achieve the tiniest slot widths and radii due to the smaller gap between wire and workpiece enabled by oil dielectric, compared to water and comparable wire diameter.

CUT 2000 OilTech

AgieCharmilles CUT 2000 OilTech
AgieCharmilles CUT 2000 OilTech
1/
Greater design flexibility

Greater design flexibility

Achieve ultrafine radii over large heights. Increase your design flexibility and forget about manual guide changes when using different wire diameters.

Uncompromising accuracy

Uncompromising accuracy

Get it right the first time: Increase repeatability on multicavity dies with our X-treme version.

Specifications

CUT 2000 S / CUT 2000 X

Main Specifications

Main Specifications
Travel X, Y, Z

350 x 250 x 256 mm

13.77 x 9.84 x 10 in
Min. surface roughness RA 0.07 μm
Max. taper angle / height

30/100° mm

30/3.93° in
Max. workpiece dimensions *

750 x 550 x 250 mm

29.5 x 21.6 x 9.8 in
Max. workpiece weight (with bath)

200 kg

440 lbs

Workpiece

Workpiece
Travel U, V

± 70 mm

± 2.7 in
Wire diameters

0.10 - 0.30 (0.05-0.07 optional) mm

0.004 - 0.012 (0.002-0.003 optional) in
Max. wire spool weight

25 kg

55.11 lbs
CUT 3000 S / CUT 3000 X

Main Specifications

Main Specifications
Travel X, Y, Z

500 x 350 x 256 mm

19.7 x 13.77 x 10 in
Min. surface roughness RA 0.07 μm
Max. taper angle / height

30/100° mm

30/3.93° in
Max. workpiece dimensions *

1050 x 650 x 250 mm

41.3 x 25.6 x 9.8 in
Max. workpiece weight (with bath)

400 kg

880 lbs

Workpiece

Workpiece
Travel U, V

± 70 mm

± 2.7 in
Wire diameters

0.10 - 0.30 (0.05 - 0.07 optional) mm

0.004 - 0.012 (0.002 - 0.003 optional) in
Max. wire spool weight

25 kg

55.11 lbs
CUT 2000 Oiltech

Main Specifications

Main Specifications
Travel X, Y, Z

350 x 250 x 256 mm

13.77 x 9.84 x 10 in
Min. surface roughness RA

0.05 μm

2 μin
Max. taper angle / height

3/100° mm

3/3.93° in
Max. workpiece dimensions *

750 x 550 x 250 mm

29.5 x 21.6 x 9.8 in
Max. workpiece weight 200 kg

Workpiece

Workpiece
Travel U, V

± 70 mm

± 2.7 in
Wire diameters

0.10 - 0.30 (0.05-0.07 optional) mm

0.004 - 0.012 (0.002-0.003 optional) in
Max. wire spool weight

25 kg

55.11 lbs
