AgieCharmilles CUT 2000/3000 Series

Link accuracy with productivity

AgieCharmilles CUT 2000/3000 Series is the perfect balance between productivity and accuracy. Extremely accurate, flexible and capable to bring complete and integrated solutions to your manufacturing challenges. Get ready to obtain uncompromised quality of results in accuracy or surface finish to achieve highest part quality and optimize productivity.

CUT 2000 S/X - CUT 3000 S/X

AgieCharmilles CUT 2000 OilTech

The CUT X000 series’ OilTech versions are designed to deliver excellent surface integrity and finish. Benefit from the best surface quality for your most demanding applications.

CUT 2000 OilTech

Specifications

CUT 2000 S / CUT 2000 X

Main Specifications

Main Specifications

Travel X, Y, Z

350 x 250 x 256 mm

13.77 x 9.84 x 10 in

Min. surface roughness RA 0.07 μm
Max. taper angle / height

30/100° mm

30/3.93° in

Max. workpiece dimensions *

750 x 550 x 250 mm

29.5 x 21.6 x 9.8 in

Max. workpiece weight (with bath)

200 kg

440 lbs

Workpiece

Workpiece

Travel U, V

± 70 mm

± 2.7 in

Wire diameters

0.10 - 0.30 (0.05-0.07 optional) mm

0.004 - 0.012 (0.002-0.003 optional) in

Max. wire spool weight

25 kg

55.11 lbs

CUT 3000 S / CUT 3000 X

Main Specifications

Main Specifications

Travel X, Y, Z

500 x 350 x 256 mm

19.7 x 13.77 x 10 in

Min. surface roughness RA 0.07 μm
Max. taper angle / height

30/100° mm

30/3.93° in

Max. workpiece dimensions *

1050 x 650 x 250 mm

41.3 x 25.6 x 9.8 in

Max. workpiece weight (with bath)

400 kg

880 lbs

Workpiece

Workpiece

Travel U, V

± 70 mm

± 2.7 in

Wire diameters

0.10 - 0.30 (0.05 - 0.07 optional) mm

0.004 - 0.012 (0.002 - 0.003 optional) in

Max. wire spool weight

25 kg

55.11 lbs

CUT 2000 Oiltech

Main Specifications

Main Specifications

Travel X, Y, Z

350 x 250 x 256 mm

13.77 x 9.84 x 10 in

Min. surface roughness RA

0.05 μm

2 μin

Max. taper angle / height

3/100° mm

3/3.93° in

Max. workpiece dimensions *

750 x 550 x 250 mm

29.5 x 21.6 x 9.8 in

Max. workpiece weight 200 kg

Workpiece

Workpiece

Travel U, V

± 70 mm

± 2.7 in

Wire diameters

0.10 - 0.30 (0.05-0.07 optional) mm

0.004 - 0.012 (0.002-0.003 optional) in

Max. wire spool weight

25 kg

55.11 lbs
