AgieCharmilles CUT P Pro Series

Precise, Consistent, Performant
With reliable mechanics, advanced technology features and a new HMI, the new CUT P PRO series delivers unmatched precision and performance for EDM application.

Make your life easier

Reduce manual interventions and gain processing time with the Automatic Slug Welding (ASW) functionality for welding to the cavity to easily remove the core before finishing cuts and Automatic Slug Management (ASM) requiring no operator presence. Both functionalities reduce your operator’s presence in front of the machine.

Maintain workpiece-independent precision

Preserve stable accuracy during axis movement, thanks to the QUADRAX system. The workpiece does not move, the axes’ mass is constant, and the axes are independent. In addition, the base has a lower thermal conductivity and a vibration damping system.

Smart consumables

SMART wire spools are equipped with radio frequency identification (RFID) chips to store wire characteristics and traceability-related data. This feature equips the CUT P and makes it truly a smart solution! Improve your production process, achieve full traceability and share technical issues in an efficient manner.

CUT P 350 Pro / CUT P 550 Pro / CUT P 800 Pro

Faster cutting speed

Achieve the quintessence of productivity with our latest-generation Intelligent Power Generator (IPG).

Cost per part

Reduce your cost per part and increase the number of parts produced with dedicated technologies for AC Cut VS+ wire.

Running costs

Reduce your running costs with our Eco machining functionalities.

Wire consumption

Significantly reduce the highest cost-intensive influence on running costs, thanks to optimized wire feed rate and faster technologies with the Intelligent Power Generator (IPG).

Step into the future

The time you spend cutting is the time you are making money. That’s why GF Machining Solutions optimizes your productivity and machine availability with SMART and connected solutions.

Establish your autonomy WorkShopManager and CellManager take you to the next level of flexibility.

Ensure quality with monitoring and traceability eTracking digitizes your process monitoring.

Closer support for you Secure highest availability with rConnect.

Manage your resources Increase your efficiency with smart consumables.

CUT P 1250

Specifications

CUT P 350 Pro

Main Specifications

Main Specifications

Travel X, Y, Z *

350 x 250 x 220 mm

13.77 x 8.66 x 8.66 in

Min. surface roughness RA 0.08 μm
Max. taper angle / height

± 30/220 (45/220 optional)° mm

± 30/8.66 (45/8.66 optional)° in

Max. workpiece dimensions *

1000 x 550 x 220 mm

39.37 x 21.65 x 8.66 in

Max. workpiece weight

750 kg

1653 lbs

Workpiece

Workpiece

Travel U, V **

350 x 220 mm

13.77 x 8.66 in

Wire diameters

0.15 - 0.33 (0.07-0.10 optional) mm

0.006 - 0.013 (0.003 - 0.004 optional) in

Max. wire spool weight 8 (25 optional)  kg

* Width x depth x height ** Width x depth

CUT P 550 Pro

Main Specifications

Main Specifications

Travel X, Y, Z *

550 x 350 x 400 mm

21.65 x 13.77 x 15.75 in

Min. surface roughness RA 0.08 μm
Max. taper angle / height

± 30/400 (45/400 optional)° mm

± 30/15.75 (45/15.75 optional)° in

Max. workpiece dimensions

1200 x 700 x 400 mm

47.24 x 27.56 x 15.75 in

Max. workpiece weight

1500 kg

3307 lbs

Workpiece

Workpiece

Travel U, V **

550 x 350 mm

21.65 x 13.77 in

Wire diameters

0.15-0.33 (0.07-0.10 optional) mm

0.006-0.013 (0.003-0.004 optional) in

Max. wire spool weight 8 (25 optional) kg

* Width x depth x height ** Width x depth

CUT P 800 Pro

Main Specifications

Main Specifications

Travel X, Y, Z *

800 x 550 x 510 mm

31.5 x 21.65 x 20.07 in

Min. surface roughness RA 0.1 μm
Max. taper angle / height

± 30/510 (45/510 optional)° mm

± 30/20.07 (45/20.07)° in

Max. workpiece dimensions

1300 x 950 x 510 mm

51.18 x 21.65 x 20.07 in

Max. workpiece weight

3000 kg

6614 lbs

Workpiece

Workpiece

Travel U, V **

800 x 550 mm

31.5 x 21.65 in

Wire diameters

0.15-0.33 mm

0.06-0.013 in

Max. wire spool weight 25 kg

* Width x depth x height ** Width x depth

CUT P 1250

Main Specifications

Main Specifications

Travel X, Y, Z

1250 x 850 x 100-800 mm

49.2 x 33.5 x 3.9-27.56 in

Min. surface roughness RA 0.2 μm
Max. taper angle / height

30/800 °  mm

30/31.5 ° in

Max. workpiece dimensions *

2300 x 1300 x 800 mm

90.6 x 51.2 x 31.49

Max. workpiece weight

6000 kg

13228 lbs

Workpiece

Workpiece

Travel U, V

1250 x 850 mm

49.2 x 33.5 in

Wire diameters

0.15-0.33 mm

0.006-0.013

Max. wire spool weight **

25-45 kg

55-100 lbs

* Length x depth x height ** Option
