Série AgieCharmilles CUT 2000/3000

Précision et productivité combinées

La série AgieCharmilles CUT 2000/3000 est l’équilibre parfait entre productivité et précision. Précision extrême et flexibilité s’allient à la capacité d’apporter des solutions complètes et intégrées à vos défis de fabrication. Préparez-vous à obtenir une qualité de résultats sans concession dans la précision ou l'état de surface pour atteindre une qualité de pièce exceptionnelle avec une productivité optimisée.

CUT 2000 S/X – CUT 3000 S/X

AgieCharmilles CUT 2000 OilTech

Les versions OilTech de la série CUT X000 sont conçues pour fournir une excellente intégrité de surface et un état de surface optimal. Bénéficiez de la meilleure qualité de surface pour vos applications les plus exigeantes.

CUT 2000 OilTech

Caractéristiques techniques

CUT 2000 S / CUT 2000 X

Main Specifications

Main Specifications

Travel X, Y, Z

350 x 250 x 256 mm

13.77 x 9.84 x 10 in

Min. surface roughness RA 0.07 μm
Max. taper angle / height

30/100° mm

30/3.93° in

Max. workpiece dimensions *

750 x 550 x 250 mm

29.5 x 21.6 x 9.8 in

Max. workpiece weight (with bath)

200 kg

440 lbs

Workpiece

Workpiece

Travel U, V

± 70 mm

± 2.7 in

Wire diameters

0.10 - 0.30 (0.05-0.07 optional) mm

0.004 - 0.012 (0.002-0.003 optional) in

Max. wire spool weight

25 kg

55.11 lbs

CUT 3000 S / CUT 3000 X

Main Specifications

Main Specifications

Travel X, Y, Z

500 x 350 x 256 mm

19.7 x 13.77 x 10 in

Min. surface roughness RA 0.07 μm
Max. taper angle / height

30/100° mm

30/3.93° in

Max. workpiece dimensions *

1050 x 650 x 250 mm

41.3 x 25.6 x 9.8 in

Max. workpiece weight (with bath)

400 kg

880 lbs

Workpiece

Workpiece

Travel U, V

± 70 mm

± 2.7 in

Wire diameters

0.10 - 0.30 (0.05 - 0.07 optional) mm

0.004 - 0.012 (0.002 - 0.003 optional) in

Max. wire spool weight

25 kg

55.11 lbs

CUT 2000 Oiltech

Main Specifications

Main Specifications

Travel X, Y, Z

350 x 250 x 256 mm

13.77 x 9.84 x 10 in

Min. surface roughness RA

0.05 μm

2 μin

Max. taper angle / height

3/100° mm

3/3.93° in

Max. workpiece dimensions *

750 x 550 x 250 mm

29.5 x 21.6 x 9.8 in

Max. workpiece weight 200 kg

Workpiece

Workpiece

Travel U, V

± 70 mm

± 2.7 in

Wire diameters

0.10 - 0.30 (0.05-0.07 optional) mm

0.004 - 0.012 (0.002-0.003 optional) in

Max. wire spool weight

25 kg

55.11 lbs
