Unique granite-based mechanical design. Get the enhanced productivity that comes from achieving high and constant speed, thanks to this solution’s core design principle: short structural loops for a low center of gravity. Granite delivers thermal stability due to its low thermal expansion coefficient.
Experience the perfect combination of precision and flexibility in one Laser solution and machine even the most complex designs in a single setup—all with unmatched part quality and an optimized workflow.
Easily handle small, thin-walled parts and avoid the risk of scrapped parts, thanks to our smart clamping tool. This innovative concept manages and clamps your parts without damage.
Minimize material lost during the machining process, achieve superior, burr-free surface finishing, and get dimensional control—all thanks to femtosecond Laser pulses allowing clean material ablation.
Achieve perfect cuts in seconds and produce medical devices in a single process thanks to the reduced heat-affected zone (HAZ) enabled by femtosecond Laser. Engrave a wide range of materials—burr-free.
Benefit from the repeatable precision and quality delivered by this solution’s ironless linear motors combined with high-resolution glass scales and its effective beam shape.
Profit from high throughput rates and produce little to no scrap with this Automation-ready solution requiring no consumables or dedicated tooling.
Simplify your operator's life and reduce scrap by creating simple to complex parts in a single setup.
Main specifications
Main specifications |
|
Machine dimensions* |
1600 x 2000 x 2000 mm 62.992 x 78.74 x 78.74 in |
Machine weight |
2300 kg 5070.58 lbs |
| Travel paths of axes X, Y, Z | 280 x 20 x 24 mm 11.024 x 0.787 x 0.945 in in |
Spindle speed |
1000 rpm |
Laser sources |
40 w |
* Width x depth x height
