Machinery and general mechanics

Productivity is a key factor in the machinery and general mechanics industry, as it helps to keep costs down and maintain competitiveness in the market.

Productivity and cost pressure forces market actors to refine their machining processes towards quality and efficiency. To achieve that goals, parts should be finished with at least steps as possible. Even with a lot of material removal the parts should feature the required quality without additional handling.

Our market-oriented solutions

Step-Tec HPC 150 platform

The HVC/HPC 150 Spindle platform offers a minimal diameter of 150mm and can accomodate  higher diameters. This platform combines the advantages of a HVC platform, first of all the high speed and the advantages of the HPC platform, the power and torque for extended roughing. This platform solution is perfectly suited when it comes to high material removal combined with high surface quality. Therefore it offers many advantages:  In-house manufactured extrem round shafts for surface quality, Cool-Core technology and Opticool-System for polar temperature stability and thus enabling reliability and optional an AE-sensor for advanced grinding.





The HVC/HPC 150 One Touch spindle is ideal for finishing parts in a single clamping, with a maximum speed of 24,000 rpm and 41 Nm (S6 40%) of torque.

Step-Tec HPC 190 platform

The HPC 190 Spindle platform offers a minimal diameter of 190mm and can accomodate  higher diameters. As an HPC platform it provides the necessary power, torque and speed for part production, roughing and finishing requiring Machinery and General Mechanics industry. Typical use cases are gear parts or stamping tools. With the HPC 190 platform you get the possibility to mill, grind and turn within one clamping through our optional spindle shaft interlock and AE sensor.





The HPC 190 One Touch spindle can mill, grind and turn, rough and finish, all in a single clamping, with a maximum speed of 20,000 rpm, 36 kW (S6 40%) of power and 120 Nm (S6 40%) of torque.

Step-Tec HPC 240 platform

The HPC 240 Spindle platform offers a minimal diameter of 240mm and can accomodate  higher diameters. As an HPC platform it provides the necessary power, torque and speed for the roughing and finishing of precision parts and for part production purposes within the highly cost-sensitive Transportation industry. The HPC 240 provides the optimal solution due to it`s wide range for taking opportunities for business development. Short spindles for tilting heads boosting your go to market efficiency, Twin Air Sealing for machining new and mud sensitive materials like composite and the spindle shaft interlock for enabling millturn processes.





The HPC 240 spindle is perfectly suited to finishing parts in a single clamping. Mill, grind and turn, finish and rough, with a maximum speed of 18,000 rpm, 38 kW (S6 40%) of power and 202 Nm (S6 40%) of torque.

Step-Tec HPC 290 platform

The HPC 290 Spindle platform offers a minimal diameter of 290mm and can accomodate higher diameters. As an HPC platform it provides the necessary power, torque and speed for the roughing and finishing of parts within the Machinery and General Mechanics industry. Its wide coverage allow the machining of large structural parts, even with multiple processes due to it`s radial effort up to 800Nm through the optional spindle shaft interlock. As options, the HPC 290 platform provides the most advanced process monitoring sensors on the market, thus supporting advantageously continuous manufacturing process improvement.





The HPC 290 Preciprod spindle provides outstanding torque of 438 Nm (S6 40%) to achieve the highest productivity on large parts.
